Steel Wire Products

Hard Drawn Steel Wires

JIS G 3521 SWA/B/C, ASTM A 679, AS1472, BS5216, DIN17233
Diameter : 0.60 - 10.00mm
Usage : Bed Spring, Spoke, Screen Wire, Flat Wire, Zig-zag Spring.

Galvanized Steel Wires/Strand

JIS C 3547/3548, ASTM B498, BS4565,DIN48200,
Diameter : 1.85 - 7.00mm
Usage : Guy Strand, ACSR, Baling Wire ,Messenger Wire,

ASTM A475, BS 183, JIS G3537,
Diameter : 7/32" 1/4" 9/32" 5/16" 3/8" 7/16" 1/2" 9/16" 5/8"
Usage : Self Support Cable, Guystrand, ACSR,

Prestressed Concrete Wire

ASTM A421(WA/WB),BS5896(1570-1670N/mm2),JIS G3536(SWPR 1,SWPD1)
Diameter : 3.0/4.0/4.5/5.0/6.0/7.0mm, Plain Round/Indented type
Usage: Pole, Pile, Slab, Railway Sleeper,

7-Wire PC Strand, Coated, unbonded

ASTM A416(250,270), BS8596, JIS G 3536(SWPR 7BL, SWPR 7AL)
Diameter : 5/16", 3/8", 7/16" 1/2" 3/5"
Usage:Beam of Bridge,Slab and Beam of Building,Tank of Gas and Water,Anchor

(HDPE coated PC Strand with Grease)
JIS G3536(SWPR 7BL), Low Relaxation, Plain,
Inner Diameter : 12.7/15.2mm, Outer Diameter : 15.3/17.8mm
Usage : Anchor, Construction

PC 2 or 3 Wire Strand

JIS G3536 Low Relaxation
Diameter : 2.9mm x 2, 2.9mm x 3, 3.0mm x 3
Usage : Railway Sleeper

PC Cable (7x7, 19x7)

JIS G3536 Low Relaxation,Plain, SWPR 7B, Non-performed, without PE Coating,
28.5mm(9.5x7), 33.3mm(11.1x7), 38.1mm(12.7x7)
45.6mm(15.2x7), 47.5mm(9.5x19), 55.5mm(11.1x19)
Usage : Anchorage of Harbor Construction
