Hot-Dip Zinc Coated
JIS G 3302 SGHC,SGH,SGCC,SGCH,SGCD,SGC
ASTM A 361, ASTM A 653, ASTM A 924,
BS 3083-88, BS EN 10142-91, BS EN 10143-93, BS EN 10147-92
DIN 59231-53
ISO 3575-76(01/02/03/04/05), ISO 4998-96(220/250/280/550)
Australia/N.Z. AS1397 G250 Z275
Electrolytic Zinc-coated
JIS G 3313 SEHC, SEHD, SEHE, SEFH, SE, SEPH, SECC, SECD, SECE, SEFC
ASTM A 591
BS EN 10152-94, DIN EN 10152-93, NF EN 10152-94
ISO 5002-82
Hot-Dip Aluminum Coated
JIS G 3314 SA1C, SA1D, SA1E, SA2C
ASTM A 463
BS EN 10215-95
ISO 5000-93
Zinc - Aluminum Coated
JIS G 3317 SZAHC, SZAH, SZACC, SZACH, SZACD, SZAC
ASTM A 875, ASTMA 924
ISO 14788-98
Dimensions
| Thickness(mm) | Width(mm) | Length(mm) | Coil I.D.(mm) | Coil Weight |
|---|---|---|---|---|
| 0.40 - 3.00 | 30 - 1,520 | 0.45 | 420 - 610 | 5 - 20MT |
Quality of JIS G 3302
| Grade | Thickness(mm) | Applications |
|---|---|---|
| SGHC | 1.6 - 6.0 | Commercial Quality |
| SGH340, SGH400 SGH 440, SGH490, SGH 540 | 0.25 - 3.2 | Structural Quality |
| SGCC | 0.11 - 1.0 | Commercial QualityCommercial Quality |
| SGCH | 0.40 - 2.3 | Commercial Quality, Hard Class |
| SGCD1 | 0.60 - 2.3 | Drawing Quality, Class-1 |
| SGCD2 | Drawing Quality, Class-2 | |
| SGCD3 | 0.60 - 2.3 | Drawing Quality, Class-3 |
| SGC340, SGC400 | 0.25 - 3.2 | Structural Quality |
| SGC440, SGC490 | ||
| SGC570 | 0.25 - 3.0 |
Surface Finish
R ( Nominal Spangle) - spangles as a result of the unrestricted growth of zinc crystals during normal solidification
Z ( Minimized Spangle) - spangles obtained by restricting normal spangle formation to a minimum
Minimum, Coating Mass for Coated Sheet/Coil
(total mass on both surfaces, g/m3)
| Type | Symbol | Average Mass | Minimum Coating at |
|---|---|---|---|
| in Triple-Spot Test | Single Spot Test | ||
| Non-alloyed | (Z06) | (60) | (51) |
| Z08 | 80 | 68 | |
| Z10 | 100 | 85 | |
| Z12 | 120 | 102 | |
| Z18 | 180 | 153 | |
| Z20 | 200 | 170 | |
| Z22 | 220 | 187 | |
| Z25 | 250 | 213 | |
| Z27 | 275 | 234 | |
| Z35 | 350 | 298 | |
| Z45 | 450 | 283 | |
| Z60 | 600 | 510 | |
| Alloyed | (F04) | (40) | (34) |
| F06 | 60 | 51 | |
| F08 | 80 | 68 | |
| F10 | 100 | 85 | |
| F12 | 120 | 102 | |
| (F18) | (180) | (153) |
Temper Grade
| Temper Grade | Symbol | Hardness(HRB) | Hardness (Hv) |
|---|---|---|---|
| As Annealed | A | ||
| Standard Temper | S | ||
| 1/8 Hard | 8 | 50 - 71 | 95 - 130 |
| 1/4 Hard | 4 | 65 - 80 | 115 - 150 |
| 1/2 Hard | 2 | 74 - 89 | 135 - 185 |
| Full Hard | 1 | 85 min | 170 min |
Quality of JIS G 3313
| Thickness(mm) | Application | |
|---|---|---|
| Main use | Base Metal | |
| 1.6-4.5 | Commercial Quality | SPHC |
| 1.6-4.5 | Drawing Quality | SPHD |
| 1.6-4.5 | Deep Drawing Quality | SPHE |
| 1.6-4.5 | Forming Quality | SEFH490/540/590 |
| 2.0-4.0 | Improved Forming Quality | SEFH540Y/590Y |
| 1.6-4.5 | General Structural Quality | SS330/400/490/540 |
| 1.6-4.5 | Structural Quality | SEPH310/370/400/440 |
C - Chromate Treatment
P - Phosphate Treatment
M - Untreatment
Remarks : Unless specified, materials shall be Chromate Treatment
Surface Finish for the Application
| Regular Spangle Z 06-Z60 | Minimized Spangle Z 06-Z60 | Ultra Smooth Z 06-Z60 | Zero Spangle Z 06-Z60 | Galvannealed Finish F04-F18 |
|---|---|---|---|---|
 |
 |
 |
 |
 |
| Structural Quality | Commercial Quality Drawing Quality Structural Quality | Commercial Quality Drawing Quality Structural Quality | Commercial Quality Drawing Quality Structural Quality | Commercial Quality Drawing Quality Structural Quality |
| Construction Guard Rail | Home Appliances Office Furniture Steel Furniture | Home Appliances Office Furniture Steel Furniture | Home Appliances Office Furniture Steel Furniture | Home Appliances Building Materials Auto-Parts |
Minimized Spangle - Characteristics of the crystal structure due to the restricted growth of zinc crystals during normal solidification, good appearance after painting due to uniformity of the surface, and better paintability compared to regular spangle.
Zero Spangle - Difficult to check the crystal grains with naked eyes due to complete suppression of the surface and outstanding appearance.
Extra smooth - Smooth surface by temper rolling after the solidification.
Good appearance after painting due to surface smoothness.
Standard Packing
Special care is given to prevent abrasion, rust and scratch during transportation and shipment, the procedures are illustrated as follows.
Unit weight is usually 2-5mt for sheet, 4-20mt for coils upon to the request.
